Insertional vs Mid-Portion Achilles Tendinopathy: Why the Difference Matters
If you have been told you have Achilles tendonitis and the treatment is not working, it is worth asking which type you actually have. In most cases of Achilles tendinopathy that we see, patients often see it as a single condition. That is not true. Achilles tendinopathy has two distinct anatomical patterns, insertional and mid-portion, and they respond to meaningfully different treatment protocols. Patients who are given a generic Achilles plan that does not match the specific type often spend months stretching, resting, and loading the wrong way before realising the plan was never built for their case.
So, if you are reading this, you are likely one of those who is struggling to recover from your Achilles pain. Let us help by walking you through the two types of Achilles tendinopathy, why the distinction matters clinically, what differs in the management approach, and what to ask if your current plan is not producing results.
A Quick Refresher on the Achilles Tendon
The Achilles tendon is the largest and strongest tendon in the body. From the anatomy of the heel, the tendon connects the calf muscles (gastrocnemius and soleus) to the calcaneus, the heel bone. Its job is to transfer the force of the calf contraction to the foot, lifting the heel and pushing the body forward with every step. The tendon experiences forces of several times body weight during running and jumping, which is why it is one of the most commonly injured tendons in active adults.
Achilles tendinopathy refers to a continuum of tendon changes ranging from acute inflammation in early cases to structural disorganisation of the collagen fibres in chronic cases. The condition presents with pain, stiffness, and reduced tolerance to load and, in chronic cases, may include visible thickening of the tendon. Most cases get better with progressive load training and load management. The catch is that the loading protocol that works for one anatomical pattern does not necessarily work for the other.
Mid-Portion Achilles Tendinopathy: What and Where
Mid-portion Achilles tendinopathy involves the part of the tendon roughly 2 to 6 cm above where it attaches to the heel bone. This is the section of tendon with the lowest blood supply, which makes it vulnerable to overuse injury. It tends to be more common among younger and middle-aged active adults, particularly runners, and that is true from what we see in our clinic.
Clinical features that point to mid-portion involvement:
- Pain and tenderness when pressing the tendon 2 to 6 cm above the heel bone, not at the heel itself
- A palpable thickening or nodule in the middle of the tendon in chronic cases
- Morning stiffness in the back of the lower leg that eases after walking
- Pain that worsens with activity, particularly running or jumping, and improves with rest in early cases
- A history of sudden increases in training volume, a change to a lower-drop running shoe, or a quick transition to a more demanding training program
- More acute in nature, so early cases usually start after an intense workout
Mid-portion tendinopathy responds well to a specific loading protocol: eccentric heel raise exercises performed slowly, daily, over 8 to 12 weeks. The evidence base supporting eccentric loading for mid-portion Achilles tendinopathy is robust, and most cases improve significantly within 12 weeks when the protocol is followed consistently.
Insertional Achilles Tendinopathy: What and Where
Insertional Achilles tendinopathy involves the very last portion of the tendon, where it attaches to the calcaneus. We call this spot the enthesis, which explains why this is sometimes referred to as Achilles enthesopathy. This is anatomically distinct from the mid-portion because the tissue at the insertion has different load-bearing properties, and because the bony anatomy of the heel itself can contribute to the irritation. The condition is more common in older adults, in patients with Haglund’s deformity, and in those whose calf muscles have been chronically tight for years.
Clinical features that point to insertional involvement:
- Pain and tenderness directly at the back of the heel bone, where the tendon meets the bone, not higher up in the tendon
- Tenderness on the inner and outer sides of the tendon insertion
- Morning stiffness localised to the heel rather than the lower leg
- Pain that worsens with uphill walking, stairs, or any activity that loads the foot in dorsiflexion (toes pulled toward the shin)
- Visible bony bump at the back of the heel in many cases, which could be from Haglund’s deformity or a developed posterior heel spur
- Pain that does not improve, and sometimes worsens, with standard eccentric heel raise protocols performed off a step
- More chronic in nature, the tendon degeneration often accumulate over years before symptom arise
The last point is the most important one for differentiating the two. The classic eccentric loading protocol involves dropping the heel below the level of the toes (the “off-the-step” position), which puts the Achilles tendon into maximum dorsiflexion. For mid-portion tendinopathy, this position loads the tendon effectively without aggravating the insertion. For insertional tendinopathy, this position compresses the tendon against the back of the heel bone and often makes symptoms worse.
Insertional Achilles tendinopathy tends to be more difficult to manage as it is more chronic in nature. We usually see patients who already have a prominent posterior heel spur or already have calcific changes in the tendon when they present to seek treatment. With such significant tendon changes in place, recovery journey will be longer, and more treatment modalities are required.
Need Help? See A Podiatrist Today
Why the Distinction Matters
Three reasons.
Different loading protocols. Mid-portion tendinopathy responds to full-range eccentric heel raises performed off a step, dropping the heel below the toes. Insertional tendinopathy requires the same heel-raise pattern, performed on level ground and without dropping below neutral, to avoid compressing the insertion. Same exercise category, completely different execution. A patient with insertional tendinopathy doing off-the-step eccentrics is loading their tendon in the one position it cannot tolerate.
Different footwear approaches. Insertional tendinopathy often improves with a small heel lift in shoes, which reduces dorsiflexion at the Achilles insertion and decompresses the area. Mid-portion tendinopathy is more about overall load management and gait, with heel lifts being less helpful in most cases. Footwear recommendations differ accordingly.
Different timelines and treatment escalation. Mid-portion tendinopathy typically improves within 8 to 12 weeks of consistent eccentric loading. Insertional tendinopathy can take 3 to 6 months, sometimes longer, particularly if the underlying bony anatomy is contributing. When extracorporeal shockwave therapy is added for chronic cases, the application protocol also differs between the two types. Extracorporeal shockwave therapy is well supported in the literature for both types, but the energy levels and number of sessions can vary based on which part of the tendon is involved.
A Practical Self-Check
You can easily do a rough self-check at home to identify which type is more likely.
Sit with your foot relaxed. Run your finger up the back of your heel and the lower part of your calf, gently pressing along the Achilles tendon as you go.
If the area of greatest tenderness is at the back of the heel bone itself, where the tendon meets the bone, the picture is more consistent with insertional tendinopathy.
If the area of greatest tenderness is 2 to 6 cm above the heel bone, in the middle of the tendon (which feels like a bouncy bowstring), with a possible feeling of a swollen small nodule, the picture is more consistent with mid-portion tendinopathy.
If both areas are tender, you may have features of both. This combination is not uncommon and changes the management plan even further.
This self-check is a starting point, not a definite diagnosis. The clinical examination by a podiatrist in Singapore is still important to confirm which structures are actually involved, and how severe the structural damage is.
Management That Matches the Diagnosis
The management plan for either type starts with a comprehensive lower limb assessment that confirms which part of the tendon is symptomatic and identifies contributing factors such as gait pattern, foot structure, footwear, calf flexibility, and training history.
For mid-portion Achilles tendinopathy, the foundation is progressive eccentric loading through heel raises performed off a step, with the heel dropping below the toes during the lowering phase. The protocol typically starts with double-leg raises and progresses to single-leg, building up volume over weeks. Activity modification is part of the plan during the initial weeks, with a structured return to running and impact activity once the tendon shows clear improvement.
For insertional Achilles tendinopathy, the foundation is the same heel raise pattern but executed on level ground, without dropping below neutral. Heel lifts are often added inside daily and training shoes to reduce dorsiflexion at the insertion. Custom foot orthotics with appropriate heel cushioning and any Haglund’s-related considerations are prescribed where indicated. Where Haglund’s deformity coexists, footwear modification to remove pressure from the bony prominence becomes essential to the plan.
In both types, where conservative management has not produced sufficient improvement at 12 weeks, extracorporeal shockwave therapy or radial pressure wave therapy can support tissue remodelling. Rehabilitation through Straits Physiotherapy works alongside the foot-level management.
What This Means for You
If you have been told you have Achilles tendonitis and the plan is “rest and stretch” without a thorough assessment, that plan was designed for an era before the two types were well distinguished clinically. Modern management has to be type-specific.
The most common pattern we see in the clinic is a patient who has been doing off-the-step eccentric heel raises diligently for months for what turns out to be insertional tendinopathy. The exercise is correct for one type. It is the wrong execution for the other. Changing the protocol, sometimes by something as small as keeping the heel above neutral instead of dropping below, can produce noticeable improvement within 2 to 4 weeks.
If your heel pain treatment has not provided improvement despite being consistent with the plan, the next useful step is an assessment that confirms which type you actually have and adjusts the plan accordingly. Speak with our team and book a consultation for an assessment at any of our three Singapore locations.
